STD-ADZ120-C8 power supply. The conversion efficient of this model is more than 88%,with output over-current protection,short circuit protection,constant output voltage,etc.
Input Voltage: 100-240 V- 50/60 Hz
Adjustable Voltage: 12 V/13.5 V/15 V
Working Humidity: 20-90%RH,no condensation Storage Humidity: 10-90%RH
Working Temperature: -20-45 °C
Input Current: 2.6 A/1.3 A
Load Loss: 1 W
Output Ripple: 120 mVpp-150 mVpp Storage Temperature: -25-65 °C
|
Model |
Input VoKage |
Output Voltage (adjustable) |
Output Current (per CH) |
Output Channel |
Output Power (Max} |
|
STD-ADZ120-C8 |
100-240 V- |
12 V |
1 A |
8 |
96 W |
|
|
100-240 V- |
13.5 V |
1 A |
8 |
108W |
|
|
100-240 V- |
15 V |
1 A |
8 |
120 W |
|
STD-ADZ60-C4 |
100-240 V- |
12 V |
1 A |
4 |
48W |
|
|
100-240 V- |
13.5 V |
1 A |
4 |
54 W |
|
|
100-240 V- |
15V |
1 A |
4 |
60 W |
